DHCE 8/60 Single Phase Electric Instantaneous Water Heaters
Description
Description
GENERAL INFO
Electronically controlled DHCE 8/60 delivers hot water instantly up to 60°C.
The STIEBEL ELTRON DHCE single phase instantaneous water heater is electronically controlled and has been designed for low flow installations with a switch on flow rate at only 1.5 litres per minute. Compact in size, the DHCE can be installed in areas where space is premium.
FEATURES | BENEFITS
- Delivers up to 60 degree Celsius hot water
- Electronically controlled
- Three selectable temperature outputs for greater convenience
- Space saving compact design
Product Details
High quality design
- Electronically controlled
- Three selectable temperature outputs for greater convenience
- Tubular heating element
- WaterMark approved, Lic. No. WMKA21273, AS3498
Installation flexibility
- Delivers up to 60 degree Celsius hot water
- No safe tray or drainage required (check local regulations)
- Space saving compact design
Efficiency
The DHCE compact water heater is electronically controlled which helps to save energy and water compared to older style hydraulically controlled instantaneous water heaters.
The compact design of the DHCE is ideal for close to the point of use installation and also helps save water and energy by reducing the lag time for hot water to arrive at the outlet.
Available in the following electrical size:
- DHCE 8/60 - 9.5kW, 40 Amps, single phase 240V
Warranty
- 5 Year full parts and labour domestic warranty*
*Conditions apply - refer warranty policy for full details.
Technical Data
| Model number | DHCE 8/60 |
| Rated output (240V) | 9.5kW |
| Rated current (240V) | 40Amp |
| Phases | 1/N/PE/AC 220..240V |
| Electrical Installation | As per AS/NZS3000 |
| Installation requirements | AS/NZS3500.4.2 & local requirements |
| Switch on flow rate (minimum flow rate required to switch on the water heater) | 1.5L/min |
| Permissible operating pressure | 1000kPa |
| Temperature adjustment | 40°C 50°C 60°C |
| IP Rating | IP25 |
| Height | 360mm |
| Width | 200mm |
| Depth | 110mm |
| Weight (filled with water) | 2.45kg |
| Colour | white |
| Nominal capacity | 0.45L |
| Approvals | WaterMark Lic No. WMKA21273, AS3498 |
| For one/several draw off points | Yes/Yes |
| Heating system | Tubular |
| Electronic flow rate control | No |
| Electronic air detection system | No |
| Accepts pre-heated water (solar) | No |
| Programmable temperature | No |
Downloads
| DHCE 8/60 Data Sheet |  |
| DHCE 8/60 Operation and Installation | |
| DHCE 8/60 Warranty | |
| Model & Serial Number Location | |
