DHCE 6/50, 8/50 Single Phase Electric Instantaneous Water Heaters
Description
Description
GENERAL INFO
Electronically controlled instant hot water up to 50°C with the DHCE 6/50 and DHCE 8/50.
The electronically controlled DHCE single phase instantaneous water heaters from STIEBEL ELTRON. These single phase instant hot water systems are ideal for low flow installations as the water heater has a switch on flow rate at only 1.5 litres per minute. With installation flexibility in mind, the DHCE hot water system is compact in design and ideal for those applications where space is tight.
FEATURES | BENEFITS
- Modern carbon look design
- Electronically controlled
- Three selectable temperature outputs for greater convenience
- Delivers a maximum of 50 degree Celsius hot water
- No safe tray or drainage required (check local regulations)
Product Details
- Modern carbon look design
- Electronically controlled
- Three selectable temperature outputs for greater convenience
- Tubular heating element
Installation flexibility
- No safe tray or drainage required (check local regulations)
- Space saving compact design
Save water and energy
The DHCE compact water heater utilises electronic control that helps to save energy and water compared to older style hydraulically controlled instantaneous water heaters.
In addition, the compact design allows for close to the point of use installation to help save water by reducing the time it takes to deliver hot water to the outlet. The advantage of an instantaneous water heater is that no heat is lost, and energy wasted, to store hot water at temperature. Energy is only required to heat water when the hot water outlet is switched on.
Available in two electrical sizes:
- DHCE 6/50 - 7.1kW, 30 Amps, single phase 240V
- DHCE 8/50 - 9.5kW, 40 Amps, single phase 240V
Warranty
- 5 year full parts and labour domestic warranty*
*Conditions apply - refer warranty policy for full details.
Technical Data
| Model number | DHCE 6/50 | DHCE 8/50 |
| Rated output (240V) | 7.1kW | 9.5kW |
| Rated current (240V) | 30Amp | 40Amp |
| Phases | 1/N/PE/AC 220..240V | 1/N/PE/AC 220..240V |
| Electrical Installation | As per AS/NZS3000 | |
| Installation requirements | AS/NZS3500.4.2 & local requirements | |
| Switch on flow rate (minimum flow rate required to switch on the water heater) | 1.5L/min | 1.5L/min |
| Permissible operating pressure | 1000kPa | 1000kPa |
| Temperature adjustment | 40°C 45°C 50°C | 40°C 45°C 50°C |
| IP Rating | IP25 | IP25 |
| Height | 360mm | 360mm |
| Width | 200mm | 200mm |
| Depth | 110mm | 110mm |
| Weight (filled with water) | 2.45kg | 2.45kg |
| Colour | Silver look | Silver look |
| Nominal capacity | 0.45L | 0.45L |
| Approvals | WaterMark Lic No. WMKA21273, AS3498 | |
| For one/several draw off points | Yes/Yes | Yes/Yes |
| Heating system | Tubular | Tubular |
| Electronic flow rate control | No | No |
| Electronic air detection system | No | No |
| Accepts pre-heated water (solar) | No | No |
| Programmable temperature | No | No |
Downloads
| DHCE Data Sheet |  |
| DHCE Operation and Installation Guide | |
| DHCE 6/50 / DHCE 8/50 Warranty | |
| Model & Serial Number Location | |
